AW3913-E-F

The AW3913-E-F is an 18-port dualband small cell Tri-Sector antenna that packages three 65° sectors in a compact 2-foot housing. It covers mid band (1695 – 2690 MHz) and high band (3300-4200 MHz). There are two mid band ports per sector and four high band ports per sector. The sectors are equally spaced with 120° separation at 0°, 120° and 240° azimuth.

The AW3913-E-F is an 18-port dualband small cell Tri-Sector antenna that packages three 65° sectors in a compact 2-foot housing. It covers mid band (1695 – 2690 MHz) and high band (3300-4200 MHz). There are two mid band ports per sector and four high band ports per sector. The sectors are equally spaced with 120° separation at 0°, 120° and 240° azimuth.

This antenna is an aesthetically pleasing solution that replaces the function of multiple sectors antennas. The AW3913-E-F provides a single fixture point to significantly reduce the cost of deployment. The antenna can be configured for mounting on lamp posts, utility poles, walls, and many other vertical structures. The AW3913-E-F’s high gain and Tri-Sector configuration provides complete azimuth coverage in a cell without the need for obtrusive infrastructure. This aesthetically pleasing solution enables network operators to locate antennas closer to users due to favourable planning views compared to other antenna solutions. The dual band AW3913-E-F supports LTE and 5G nR mid and high frequency bands including AWS, PCS, IMT, WCS, 2.5GHz BRS ,3.5 GHz CBRS, and C-band.

Canisters provide multiple antennas into one attractive package. These canisters deliver an elegant small and macro cell solution for pole-top, rooftop and street level applications. Alpha Wireless produces the highest performance, highest functionality, and smallest diameter canisters in the marketplace.

Quick Specs

Freq: 1695-2690 MHz (6 Ports)
3300-4200 MHz (12 Ports)
Ports: 18
Beamwidth: 65⁰
Gain: 14.0, 11.0

Features

  • Compact design – Low visual impact.
  • Total of six Mid-band ports and twelve 3.5GHz ports.
  • Two Mid band ports per sector and four 3.5GHz ports per sector.
  • 65° Azimuth Beamwidth on each of the three sectors.

Ordering Information

AW3913-E-F Enclosed Remote Electrical Tilt (eRET) with 4.3-10 Connectors
