AWL4015-T0-F-BL-V2
The AWL4015-T0-F-BL-V2 is an 8-port, compact multiband antenna built for high-performance 4G and 5G applications. Supporting dual bands (1695-2690 MHz and 3300-4200 MHz), this antenna enables 4×4 MIMO for enhanced data throughput in urban, low-visibility installations.
The Alpha Wireless AWL4015-T0-F-BL-V2 is an ultra-compact, high-performance 8-port multiband omni antenna designed for seamless 4G and 5G integration. Ideal for urban deployments, this small cell antenna supports dual-band functionality, with four ports dedicated to the Mid-Band (1695-2690 MHz) and four for the High Band (3.5 GHz CBRS, 3300-4200 MHz). This innovative solution enables 4×4 MIMO configurations across both bands, enhancing data throughput and supporting multi-operator use.
Engineered for low visual impact, the AWL4015 offers consistent 360° azimuth coverage with minimal nulls, making it ideal for densely populated areas. Constructed with a weather-resistant ASA capped ABS radome and reinforced for extreme temperatures (-40°C to 70°C), this antenna promises durability even in challenging environments. Additional features include pole-top and side-arm mounting options, DC grounding for lightning protection, and compliance with RoHS standards.
With easy installation and minimal maintenance, the AWL4015-T0-F-BL-V2 provides a reliable, compact solution for expanding network capacity and improving connectivity in urban areas.
Quick Specs
- Freq: 1695-2690 MHz, 3300-4200 MHz
- Ports: 4,4
- Beamwidth: 360°
- Gain: 8.0, 9.1
Features
- Allows 4×4 MIMO on dual bands for multiple operators
- Minimal nulls in the azimuth pattern for consistent azimuth coverage
- Pole-top and side-arm mounting options
- High port count enabling multiple operators
- Compact design – Low visual impact
Ordering Information
AWL4015-T0-F-BL-V2: Zero Degrees Fixed Tilt with 4.3/10 Connectors
