AW3372-T0-F
The AW3372-T0-F is a two port, 3300 – 3800 MHz, small cell panel antenna with a 65° horizontal beamwidth. The panel antenna has a 22° elevation beamwidth which provides uniform coverage in the sector. The AW3372 delivers a stable 12.5 dBi gain in a slim radome with a 13” length.
This product has been discontinued.
It has been replaced by the AW3924-T0-F, a 4-port small cell panel antenna with a 65° horizontal beamwidth that supports the entire C-band spectrum 3300 – 4200 MHz. Please Contact Us for more information.
The AW3372-T0-F is a two-port, 3300 – 3800 MHz, small cell panel antenna with a 65° horizontal beamwidth. The panel antenna has a 22° elevation beamwidth which provides uniform coverage in the sector. The AW3372-T0-F delivers a stable 12.5 dBi gain in a slim radome with a 13” length. This antenna is designed to be installed in an urban environment where low visual impact is required. The AW3372-T0-F provides sectorized coverage for 4G and 5G private networks using the 3.5 GHz Citizens Broadband Radio Service (CBRS) and C-band spectrum (bands n48 and n78, respectively).
Small Cells are a family of ultra-compact antennas that allow for network coverage and capacity increases almost anywhere. This aesthetically pleasing antenna’s small form factor allows for easier architectural approval. A number of mounting options are available and the small cell solutions can be deployed on lamp posts, utility poles, and walls. Small cell antennas support 2×2 MIMO and 4×4 MIMO with fixed and variable electrical tilt of the elevation beam.
Quick Specs
Freq: 3300-3800 MHz
Ports: 2
Beamwidth: 65⁰
Gain: 12.5
Features
- Wide-band antenna for 3GPP bands 42, 43 & 48.
- Compact design for Small Cell deployment – Low visual impact.
- Dual Cross polarization antenna +/- 45°.
- Manufactured in Ireland.
Ordering Information
AW3372-T0-F: Zero Degrees Fixed Tilt with 4.3-10 Connectors
